Infrared body temperature detection area
1.Recognition and temperature measurement can be completed in 0.3 seconds
2.Support query records by cloud system
3.Support OEM software, customize LOGO and make installation package (large quantity)
Functions:
1.Highly sensitive infrared detectors are used for monitoring and rapid temperature measurement and screening of “high-temperature individuals” in floating populations.
2.Adopt high-precision black body adjustment to accurately capture each heating element.
3.Can capture accurate face technology in on second among many people, which can simultaneously detect
4.RGB camera, accurately locate abnormal body temperature appearance, automatic sound alarm when encountering abnormal body temperature, save abnormal person’s appearance picture.
5.Support HDMI high-definition video output port, 10 inches to 100 inches television as a screen (with voice output at the same time)
6.Easy to install, no need for professional construction, just plug in the power, and HDMI can be used to connect to the television.
AI Temperature Measurement Unit
Communication Interface: USB interface x1, network port x1
Data Transmission: RJ45 cable, 100/1000Mbps self-appetite TCP/IP protocol
Working Voltage: DC12±10% 2A
Power: 15W(MAX)
Video output: HDMI2.0
Appearance Material: metal shell
Video Connection Number: 1 channel dual optical video
Capture Rate: 99.9%
Recognition rate: 98%
Processing Speed: 10 people/second
Whitelist Capacity: 80,000pcs
Visible Light Pixels: 2 million, 1/2.8 inches target surface
Visible Light Frame Rate: PAL: 1080p@25fps NTSC: 1080p@30fps
Minimum Illumination: 0.0001 Lux (F1.2, AGC ON), full color night vision
Lens Interface Type: C/CS
Protection Level: static surge level 3B
Working Temperature: -10℃ ~ 65℃
Temperature Measurement Range: 0℃ ~ 50℃
Measurement Accuracy: ±0.3℃
常用功能
專業功能
全新功能
Applications:
1.Government Agency Service Hall/Licensing Office/Bank
2.Office School Factory/Science Park/Gymnasium
3.Transportation Station/Port/Airport/Car
