Silent Lock with automatic detection function lock state, misoperation automatic correction, the lock open close the high sensitivity, the lock has the advantages of low noise, safety and reliability etc.
Silent Lock combine the virtues of electric rim lock and electromagnetic lock,overcome the loud noise of electric rim lock and high power consumption of electromagnetic lock.
Electric Control Lock They are widely used in building intercom system,access control system. Various opening methods:access control,intercom,remote control,ID card,key etc.
Working Voltage: 10-18VDC
Power On Time: 0.25s
Unlock Time: 200,000
Power line resistance: <1.5 ohm
Working Current: 900mA
Humidity: 0-95%
Holding Force:300-380kg
Working Temperature: - 20 - 60℃
Environment: -40℃~80℃
Can compatible with building access control system
Can used with building intercom and access control system
Automatically detects the door, automatic processing to open closed;
Can be installed on the left door, right door, inside door and outside door, etc
Not to enter after the lock or unlock, door locks about 9 seconds;
Voltage dc12v - dc18v, starting current is less than 350 ma, the standby current is less than 25 ma, unlock time 1 s;
Life (greater than 500000), on/off, high sensitivity on/off, low power consumption;
Using Range: applicable to all kinds of door;
The length of the lock tongue > 20 mm, meet GA 5.1.6 b/t73-94 standard;
Wiring Diagram:
